SKU: KS0218

Shield motor Drive RPI L298P Keyestudio

Regular price €9,03
Sale price €9,03 Regular price
Sale Sold out
Unit price
/per
Tax included. Shipping calculated at checkout.
Out of stock
This is a pre order item. We will ship it when it comes in stock.

Shield based on the L298P chip, which can directly drive two 2A DC motors.

Features

  • Logic part input voltage: 5V
  • Driving part input voltage: 4.8 ~ 24V
  • Logic part working current Iss: ≤36mA
  • Driving part working current Io: ≤ 2A
  • Maximum power dissipation: 25W (T=75℃)
  • Control signal input level: High level: 2.3V ≤ Vin ≤ 5V; Low level: 0V ≤ Vin ≤ 1.5V
  • Operating temperature: -25℃~+130℃
  • Driver form: Dual power H bridge driving
