SKU: KS0249

Arduino Pro Micro Keyestudio Controller Board

Regular price €9,87
Sale price €9,87 Regular price
Sale Sold out
Unit price
/per
Tax included. Shipping calculated at checkout.
In stock and ready for shipping
This is a pre order item. We will ship it when it comes in stock.

The Arduino Pro Micro controller board, from Keyestudio, is compatible with all the functionalities of the Arduino platform . It includes four analog inputs, five PWM pins, 12 digital roads/outputs and hardware serial connections Rx and Tx. It operates at a voltage of 3.3V, at a working frequency of 8MHz and is capable of accepting an external supply voltage of up to 16V (direct current). If the power is not regulated to the board, it must be connected to the 'RAW' pin.

Features

Arduino Pro Micro Controller Board

Operating voltage: 3.3V
Usable frequency: 16MHz (accepts external voltage up to 9V DC)
Microcontroller: ATMEGA32U4
RAW: 7V-9V
VCC: 3.3V at 500mA
Digital I/O pins: 12 (of which 5 provide PWM outputs)
Analog input pins: 4
Maximum chip current: 200mA
Maximum current per pin: 40mA
Recommended current per pin: 20mA
8-bit Atmel AVR
Flash program memory: 32kB
EEPROM: 1kB
Internal SRAM: 2.5kB
ADC: 10-bit
PWM: 8bit
High speed PWM with programmable resolution of 2-11 bits

Includes

Pro Micro Controller Board
USB cable
